Name: ASTM B111 C70600 Copper Nickel Steel Low Fin Tube For Hear Exchanger
Brand: Yuhong Group Co.,Ltd
SKU: ASTM B111 C70600
Price: 100,000.00 USD
Availability: InStock

A Comissão considerou que o auxílio não foi concedido em conformidade com o artigo 3.o, n.o 1, do Regulamento Financeiro.

Portuguese

ASTM B111 C70600 Copper Nickel Steel Low Fin Tube For Hear Exchanger

Detalhes do produto:

Lugar de origem:	China
Marca:	Yuhong
Certificação:	ABS, BV, ISO, ASTM, SGS
Número do modelo:	ASTM B111 C70600

Condições de Pagamento e Envio:

Quantidade de ordem mínima:	100kgs
Preço:	Negociável
Detalhes da embalagem:	Caixa / pacote / pacote de madeira com madeira com tampa de plástico
Tempo de entrega:	7-45 dias
Termos de pagamento:	L/c, t/t
Habilidade da fonte:	1000 toneladas/mês

Contato

Produto:

Baixos tubos de aleta

Especificações:

ASME SB111

Tratamento de superfície:

Personalizado

Grau de material:

C70600

Espessura da parede do tubo:

Personalizado

Comprimento:

Conforme exigência do cliente

Destacar:

ASTM B111 C70600 copper nickel fin tube

low fin tube for heat exchanger

copper nickel steel fin tube

Product Overview

The ASTM B111 C70600 Low Fin Tube is manufactured from 90/10 copper–nickel alloy (Cu ~88.7–90.0%, Ni ~9.0–11.0%). Low fins are integrally rolled from the tube’s outer surface, enhancing external surface area while keeping the inner surface smooth for fluid flow. This makes it ideal for marine, offshore, and industrial heat exchangers where seawater or brackish water is the cooling medium.

Advantages

Excellent seawater corrosion resistance due to 90/10 Cu-Ni alloy

High resistance to biofouling compared to stainless steels

Improved heat transfer efficiency with low fins (increased outer surface area)

Good mechanical strength & fatigue resistance

Long service life in marine and industrial cooling applications

Smooth inner bore ensures minimal pressure drop for fluids

Chemical Composition (ASTM B111 C70600)

Element	Content (%)
Cu (Copper)	88.7 – 90.0
Ni (Nickel + Cobalt)	9.0 – 11.0
Fe (Iron)	1.0 – 1.8
Mn (Manganese)	1.0 max
Zn (Zinc)	1.0 max
Pb (Lead)	0.02 max
Others	0.1 max

Mechanical Properties (Annealed Condition, per ASTM B111)

Property	Value
Tensile Strength (MPa)	≥ 275
Yield Strength (0.5% ext, MPa)	≥ 105
Elongation (%)	≥ 30
Hardness (HRB)	≤ 80

Fin Specification (Low Fin Tube)

Fin Type: Low fin, integrally rolled from base tube

Fin Height: Typically 0.3 – 0.5 mm

Fin Density: 19 – 26 FPI (Fins per inch), depending on design

Bond: Metallurgically integral (no risk of loosening)

Tube OD Range: 9.52 mm – 25.4 mm

Tube Length: Up to 18 meters (customizable)
