ASTM A268 TP410 Ferritic Stainless Steel Seamless Pipe For Heat Exchanger

Detalhes do produto:

Lugar de origem:	China
Marca:	YUHONG GROUP
Certificação:	ABS , GL , DNV , NK , PED , AD2000 , GOST9941-81 , CCS , ISO 9001-2008
Número do modelo:	TP410

Condições de Pagamento e Envio:

Quantidade de ordem mínima:	500 kg
Preço:	Negociável
Detalhes da embalagem:	Caixa/feixe de madeira plissada
Tempo de entrega:	Depende da quantidade
Termos de pagamento:	T/T, L/C na vista
Habilidade da fonte:	10000 toneladas/mês

Contato

Todos os Produtos

Tubo sem costura de aço inoxidável (285)

Tubo sem emenda de aço inoxidável (273)

Tubulação de aço inoxidável frente e verso (127)

Tubo de aço inoxidável frente e verso (28)

Tubo de agulha (98)

Tubos de barbatanas (608)

Trocador de calor (15)

tubo do permutador de calor (424)

Pacote de tubos de trocador de calor (37)

Permutador de calor Tubesheet (115)

defletor do permutador de calor (36)

Refrigerador de ar (7)

recipiente de pressão (4)

tubulação soldada de aço inoxidável (57)

Tubo soldado de aço inoxidável (112)

Tubulação da liga de níquel (259)

Tubo da liga de níquel (75)

Tubo da liga de cobre (219)

Tubo do aço de liga (177)

Tubo do titânio (9)

tubo recozido brilhante (153)

Tubo de caldeira (138)

encaixe de aço (791)

Flange de aço (577)

Outros (386)

Partes de revestimento (5)

Descrição de produto detalhada

Grau do material:	TP410	Padrão:	ASTM A268
Tamanho:	19.05 - 76,2 mm	W.T:	até 24mm
Comprimento:	Aleatório Único, Aleatório Duplo & Comprimento Cortado	TNN:	ET / HT / UT / PT
Embalagem:	caso/pacote Dobra-de madeira	aplicação:	Permutador de calor do gás de óleo
Destacar:	A268 Ferritic Stainless Steel Pipe , ASTM A268 Stainless Steel Pipe , TP410 Ferritic Stainless Steel Pipe

ASTM A268 TP410 Ferritic Stainless Steel Seamless Pipe for Heat Exchanger

ASTM A268 TP410 is a ferritic stainless steel grade designed for seamless pipes and tubes used in high-temperature and corrosive environments. It is widely applied in heat exchangers, condensers, and other critical applications where excellent corrosion resistance and mechanical properties are required.

Key Features:

Material Composition:
- TP410 is a martensitic stainless steel containing high chromium content, offering excellent resistance to oxidation and corrosion.
- Typical composition includes 11.5-13.5% Chromium (Cr) and 0.08-0.15% Carbon (C).
Corrosion Resistance:
- Good resistance to atmospheric corrosion, steam, and mild chemical environments.
- Suitable for applications in oxidizing and mildly corrosive conditions.
Mechanical Properties:
- High strength and good toughness after heat treatment.
- Excellent resistance to thermal fatigue and scaling.
Heat Resistance:
- Operates effectively in high-temperature environments.
- Ideal for heat exchanger systems where thermal stability is critical.

Characteristic of ASTM A268 TP410

Grade 410 stainless steel is a general-purpose martensitic stainless steel containing 11.5% chromium, which provides good corrosion resistance. However, the corrosion resistance of Grade 410 steel can be further improved through a number of processes including quenching, tempering and polishing. Quenching and tempering harden Grade 410 steels. They are typically used in applications involving mild corrosion, heat resistance and high strength.

The tubes shall have a hardness number that will not exceed the prescribed Brinell and Rockwell hardness values, TP410, TP430 and TP439 max Rockwell hardness 90HRB, Test report required certification conform to Specification A1016/A1016M.

Several mechanical tests shall be conducted, namely:

Tension test;

Flaring test (for seamless tubes);

Flange test (for welded tubes);

Hardness test;

Reverse flattening test;

Intergranular corrosion test; and

Hydrostatic or nondestructive electric test.

Chemical Composition of ASTM A268 TP410

C %	Mn %	P %	S %	Si %	Cr %
0.15 maximum	1.00 maximum	0.040 maximum	0.030 maximum	1.00 maximum	11.5-13.5

Mechanical Strength of ASTM A268 TP410

Tensile Stress, Mpa	Yield Stress, MPa	Elongation, %	Hardness, HB
415 minimum	205 minimum	20 minimum	207 maximum

ASTM A268 Stainless Steel Tubing Sizes Tolerance
Outside Diameter, In.[Mm]	OD Tolerance, In.[Mm]	Wall Thickness, %	Thin Wall Tubes
Up To1⁄2, [12.7], Excl	±0.005 [0.13]	±15
1⁄2 To 11⁄2 [12.7 To 38.1], Excl/Td>	±0.005 [0.13]	±10	Less Than 0.065 In. [1.6 Mm] Nominal
11⁄2 To 31⁄2 [38.1 To 88.9], Excl	±0.010 [0.25]	±10	Less Than 0.095 In. [2.4 Mm] Nominal
31⁄2 To 51⁄2 [88.9 To 139.7], Excl	±0.015 [0.38]	±10	Less Than 0.150 In. [3.8 Mm] Nominal
51⁄2 To 8 [139.7 To 203.2], Incl	±0.030 [0.76]	±10	Less Than 0.150 In. [3.8 Mm] Nominal

Applications:

Heat Exchangers: Used in oil refineries, power plants, and chemical industries for efficient heat transfer.
Condensers: Suitable for condensing steam or other fluids in industrial processes.
Boiler Tubes: Commonly used as boiler components in high-pressure environments.

Advantages of TP410 Ferritic Stainless Steel:
