ASTM B111 / ASME SB111 C71500 Copper Nickel Tube Heat Exchanger Tube

ASTM B111 / ASME SB111 C71500 Copper Nickel Tube Heat Exchanger Tube

ASTM B111 is a standard developed by the American Society for Testing and Materials, known as the "Standard Specification for Copper and Copper Aluminum Seamless Condenser Tubes and Ferrule Stock". It specifically specifies the chemical composition, mechanical properties, dimensional tolerances, process requirements, inspection methods, etc. of seamless copper and copper alloy tubes used for condensers, heat exchangers, and similar heat exchange equipment. C71500 is a specific copper alloy gold number (UNS number), representing a 70/30 copper nickel alloy, which nominally contains 70% copper and 30% nickel.

ASTM B111 C71500 Copper Nickel Tube Heat Exchanger Tube Characteristics

• Excellent corrosion resistance: Excellent corrosion resistance is the most prominent advantage of C71500 copper nickel heat exchange tubes. It has strong resistance to various chemical solutions such as seawater, brackish water, steam condensate, and non oxidizing acids, salts, and alkalis. At the same time, the C71500 copper nickel heat exchange tube has excellent resistance to erosion corrosion, stress corrosion cracking, and dealloying corrosion (such as nickel removal), and is very durable in flowing seawater. It is widely used in marine environmental applications such as ships, seawater desalination plants, and coastal power stations. On the other hand, the resistance to biofouling of C71500 copper nickel heat exchange tubes is superior to some other copper alloys.
• Good mechanical performance: ASTM B111 C71500 copper nickel heat exchange tubes have higher strength and hardness than pure copper and many other copper alloys. At the same time, with good ductility and toughness, ASTM B111 C71500 copper nickel heat exchange tubes are easier to perform cold working and other hot forming processes such as bending and expanding. In addition, ASTM B111 C71500 copper nickel heat exchange tubes have good creep resistance.
• Excellent thermal conductivity: Although the thermal conductivity of ASTM B111 C71500 copper nickel heat exchange tubes is lower than that of pure copper or brass, C71500 heat exchange tubes still have significant advantages over materials such as stainless steel, about 5-10 times that of austenitic stainless steel, making them very suitable for condensers and heat exchangers that require efficient heat transfer.
• Machinability and Weldability: The machinability of ASTM B111 C71500 copper nickel heat exchange tubes is inferior to that of pure copper and aluminum brass, but superior to heat exchange tubes made of high silicon bronze and other materials; ASTM B111 C71500 copper nickel heat exchange tubes have good welding performance and can be welded using conventional welding methods such as tungsten inert gas welding, metal inert gas welding, and electrode arc welding. Usually, heat treatment is not required after welding.
• Cold resistance: ASTM B111 C71500 copper nickel heat exchange tubes can maintain good toughness and strength at low temperatures.

ASTM B111 C71500 Copper Nickel Tube Heat Exchanger Tube Chemical Composition

ASTM B111 C71500 Copper Nickel Heat Exchanger Tube Material Condition

ASTM B111 C71500 Copper Nickel Tube Application:

• Ship and Ocean Engineering: In the ship and ocean engineering industry, ASTM B111 C71500 copper nickel tubes are mainly used in the main condenser and auxiliary condenser of ship power plants, lubricating oil coolers, central coolers, fuel heaters, and can also be used in seawater pipeline systems for transporting fire water, ballast water, cooling water and other media. At the same time, they can be used as heat exchangers and evaporator pipes for seawater desalination devices, and as important connecting components in the heat exchange system of offshore oil platforms.
• Electric power industry: In the electric power industry, ASTM B111 C71500 copper nickel tubes can be used as condenser pipes for coastal thermal power plants and nuclear power plants, and are suitable for various auxiliary coolers.
• Chemical and Petrochemical: In the chemical and petrochemical industry, ASTM B111 C71500 copper nickle tubes are suitable for heat exchangers, condensers, and evaporators used to treat seawater, brackish water, and corrosive solutions such as weak acids and alkaline solutions.
• Refrigeration and Air Conditioning: ASTM B111 C71500 copper nickel tubes can be used for condensers and evaporators in large central air conditioning systems, especially in coastal or corrosive environments, and can also be used as heat exchange pipes for seawater source heat pump systems.
• Other: ASTM B111 C71500 copper nickel tubes have also been widely used in marine aquaculture systems or industrial heat exchange equipment that requires high corrosion resistance and good thermal conductivity.
